Connector locations 5-1

4500

5. Connector locations

LVPS–low voltage power supply board

Note: The LVPS part number for E320/E322 and E220/E321/E323

is different but the input/output values are the same.

Connector Pin no. Signal

CN1 1 AC H

2AC N

CN2 1 Heater on

2AC N

CN3 1 Ground

2 +5 V dc

3 +5 V dc

4Ground

5 +24 V dc

6 +24 V dc

7 Ground

8Ground

9 Heater on

10 Heater on sub
