5-6 Service Manual
4500
RIP controller (E320/E322 only)
Connector Pin no. Signal
J2 Light Op Panel 1 Ground
2FPIRQ
3Light CLK
4 Light data
5 +5 V dc
6 Ground
J3 Video 1 Video
2 Ground
J7 Controller to Engine 1 Engine POR
2 Ground
3Notify
4 Controller present
5SCL
6 Ground
7DSA
8HSYNC
9 Ground
10 VSYNC
11 Ground
12 Laser on
J8 Power 1 +5 V dc
2 Ground
