General information 1-5
4500
Printer operation
Paper is held in a 150 page tray where it is picked by a center–fed D
shape pick roller. The paper follows an L shape path as it moves
through the printer. Images are created with toner on an optical
photoconductor (OPC) drum within the toner cartridge. A transfer
roller then draws the toner off the OPC drum onto the paper. Once
the toner is affixed to the paper by the fuser, the paper exits either
the top or front of the printer.
Printer dimensions and clearance
The following table contains the dimensions for each printer model.
This does not include packaging but does include the print cartridge
that ships with the printer.
Note: Do not enclose printer on all sides without providing
ventilation.
Physical dimensions E320/E322/E322n
E220/E321/
E323/E323n)
Height 221 mm (8.7 inches) 221 mm (8.7 inches)
Width 380 mm (15.0 inches) 391 mm (15.4 inches)
Depth 368 mm (14.5 inches) 368 mm (14.2 inches)
Operating clearance
Top 203 mm (8 inches)
Left and right sides 305 mm (12 inches)
Front 152 mm (6 inches)
None required except for paper
ejection.
Rear 51 mm (2 inches)
