Lexmark E320 Service Manual

5-8 Service Manual
4500
RIP controller (E220/E321/E323 only)
Note: (I) indicates input (check with cable connected).
Connector Pin no. Signal
J1 LVPS 1 +5 V dc (I)
2, 5, 6 Ground (I)
3, 4 +24 V dc (I)
7ZEROX_C
8HR_PSU
J2 Fan 1 +24 V dc
2Return
J3 HVPS 1 DEV_C
2 Ground
3 CHARGE_C
4+24 V dc
5TX_C
6 TXENABLE_C
8 SERVO_OUT_C
J4 Toner 1 Ground
2TONER_END
3<+5 V dc
J5 LSU 1, 5, 7 Ground
2 VDO_ADJ_C
3VIDEO_C
4<LEN_C
6 +5 V dc (front cover closed)
8HSYNC_C
