Connector locations 5-9
4500
J6 Cover open 1 +5 V dc (cover closed) (I)
1 0 V (cover open) (I)
2 +5 V dc
3Ground
J7 Mirror motor 1 MM_REF_C
2MM_LOCK_C
3 MM_START_C
4Ground
5 +24 V dc
J8 Main motor 1, 6 Ground
2XPRT_FB
3 XPRT_SPEED_R
4XPRT_EN_C
5XPRT_LOCK_C
7 +24 V dc
J9 Network
(network printer only)
J10 Erase
J11 Paper Sensor 1, 4 Ground
2 PAPER_IN
3<+5 V dc
5 PAPER_OUT
6<+5 V dc
J12 Solenoid 1 FDSOL+, +24 V dc pulse
2FDSOL -
J13 Smart Chip 1 DC_DATA_C
2Ground
Connector Pin no. Signal
