Parts catalog 7-1
4500
7. Parts catalog
How to use this parts catalog
• SIMILAR ASSEMBLIES: If two assemblies contain a majority of
identical parts, they are shown on the same list. Common parts
are shown by one index number. Parts peculiar to one or the
other of the assemblies are listed separately and identified by
description.
• NA (not available) means not available as a FRU.
• NS: (not shown) in the Asm-index column indicates that the part
is procurable but is not pictured in the illustration.
• PP: (parts packet) in the parts description column indicates the
part is contained in a parts packet.
