Connector locations 5-5
4500
J12
PSU
1 +5 V dc
2Ground
3 Interlock switch
4 Interlock switch
5Ground
6Ground
7 Fuser control
8 Hot roll power
J13
Option Tray
1 Transmit
2Receive
3Tray detect
4 +5 V dc
5Ground
6 +24 V dc
Connector Pin no. Signal
