Connector locations 5-3
4500
J3
Cartridge Chip
1 Cartridge data
2Ground
J4
Fan Control
1 +24 V dc
2 Fan control
J5
Main Motor
1 +24 V dc
2Ground
3 Motor enable
4Ground
5 Motor signal
J6
Toner Sensor
1Ground
2 Toner signal
3 Light drive
J7
Thermistor
1 Thermistor data
2Ground
J8
Not used
1
2
J9
Cover Open Switch
1 +24 V dc
2 Interlock switch
J10
Paper Pick Solenoid
1 +24 V dc
2 Solenoid control
Connector Pin no. Signal
