Parts catalog 7-3
4500
* Contact Lexmark for availability.
Assembly 1: Covers (E320/E322)
Asm-
index
Part
number
Units Description
1–1 12G4456 1 Extension, tray
2 12G4455 1 Cover, rear
3 12G4458 1 Cover, bottom
4 12G4453 1 Cover, right side
5 12G4457 1 Assembly, operator panel
6* 56P1099 1 Parts pack, bushings clip spring
7 56P2373 1 Hinge, right
8 12G4535 1 Spring, front cover right
9 12G4543 1 Cover, front–E320
9 12G4542 1 Cover, front–E322
10 12G4450 1 Cover, access
11 12G4536 1 Spring, front cover left
12 56P2374 1 Hinge, left
13 12G4459 1 Duct, cooling
14 12G4451 1 Cover, left side
15 12G4452 1 Cover, top
NS 12G0176 1 Cover, media
