Parts catalog 7-9
4500
* Contact Lexmark for availability.
Assembly 2: Frame
Asm-
index
Part
number
Units Description
2–1 12G4470 1 Roll, transfer
2 12G4471 1 Bearing, transfer
3 12G4473 1 Bill of material (B/M), rail
(E320/E322 only)
3* 56P1085 1 B/M, rail (E220/E321/E323 only)
4 12G4534 1 Bracket, right
5 56P0685 1 Assembly, charge roll
6 12G4464 1 Spring, charge roll right
7 99A1017 1 Roll, charge
8 12G4463 1 Spring, charge roll left
9 12G4533 1 Bracket, left
10 12G4460 1 Fan, cooling (E320/E322 only)
11* 56P1052 1 Fan, cooling (E220/E321/E323)
12 12G4510 6 Spring, HVPS (6/FRU)
13 12G4461 1 Switch asm., power (white–110V)
13* 56P1092 1 Switch asm., power (black–110V))
13* 56P0687 1 Switch asm., power (white–220V)
13* 56P0688 1 Switch asm., power (black–220V)
14 56P0199 1 Bearing, left transfer
