Parts catalog 7-11
4500
* Contact Lexmark for availability.
Assembly 3: Fuser
Asm-
index
Part
number
Units Description
3–1 12G4488 1 Cover, fuser (E320/E322 only)
1* 56P1082 1 Cover, fuser (E220/E321/E323 only)
2 12G4484 1 Fuser assembly, 110 V
(E320/E322 only)
2 12G4486 1 Fuser assembly, 220 V
(E320/E322 only)
3 12G4493 1 Roller, exit, redrive
4 56P1053 1 Fuser assembly, 110 V
(E220/E321/E323 only)
4 56P1054 1 Fuser assembly, 220 V
(E220/E321/E323 only)
5* 56P1099 3 Parts pack, bushings/clip spring
6 12G4495 3 Pawl, detack (1 each)
7 12G4496 4 Roll assembly, idler (1 each)
8 12G4492 2 Roller, exit, idler (1 each)
9 12G4485 1 Lamp, fuser, 110 V
9 12G4487 1 Lamp, fuser, 220 V
10 12G4491 1 Roll, fuser, hot
11 12G4489 2 Bearing, backup roll
12 12G4494 1 Roll, fuser, backup
