Parts catalog 7-15
4500
Assembly 5: Paper feed
Asm-
index
Part
number
Units Description
5–1 12G4481 1 Assembly, sheet feed (white)
1 56P1079 1 Assembly, sheet feed (black)
2 12G4483 1 Assembly, D–roll (E320/E322 only)
2 56P0690 1 Assembly, D–roll
(E220/E321/E323 only)
3 12G4541 1 Clutch assembly, paper feed
(E320/E322 only)
4 56P1063 1 Clutch assembly, paper feed
(E220/E321/E323 only)
5 12G4538 1 Roller, lower registration
6 12G4540 1 Gear, registration roller
7 12G4477 1 Sensor, cartridge
8 56P1099 1 Parts pack, bushings/clip/spring
9 12G4482 1 Bracket, Tray 2 connector
10 12G4490 1 Roll, paper feed
11 56P1099 1 Parts pack, bushings/clip/spring
12 12G4476 1 Sensor, exit
13 12G4475 1 Sensor, registration
14 12G4539 2 Bushing, registration roller
15 12G4480 1 Strip, D–roll
16 12G4474 1 Roll assembly, registration
17 56P0691 1 Pad assembly, paper separator
