1-2 Service Manual

4500

Six printer models are available:

Models E320/E322

• Lexmark E320 printer with 4MB of standard memory

• Lexmark E322 printer with 8MB of standard memory

• Lexmark E322n printer with standard Ethernet and

16MB of standard memory

Rear paper support

Tray 1

Manual feed

Front paper support

Paper guide

Operator panel

lights

Optional 250-sheet tray

Front output door

Top output bin
