3-20 Service Manual
4025-XXX
• Stk Hight Upper
• Stk Hight Lower
• Stk Tray Low Lmt
• Stack Tray Pos
• Dock Interlock
• Top Cover J
• Front Cover K
• Punch Dust Box M
• H-Tra Gate
• H-Tra Cover H
• H-Tra Input Path
• H-Tra Exit Path
• Punch Dust
• Top Tray Exit
• Top Tray Full
• Top Tray Empty
To select one of the sensors, press Menu until the sensor you want is displayed. Press
Select for that sensor. The following is a sample screen that may be displayed:
Once this screen is displayed, you can manually actuate the sensor. When the sensor is
closed,
CL is displayed. Likewise, when the sensor is open, OP is displayed. If the
wrong message is displayed, then the sensor may be malfunctioning.
To exit the sensor test, press Return.
FIN Input Path
CL
