7-11 Parts Catalog
4025-XXX
Assembly 5: Tray Interface
Asm-
Index
Part
Number
Units Description
5-1 12G4024
1
STOP, TRAY R
-2 12G4027
1
SPRING, TORSION
-3 12G4026
1
LINK STOP, TRAY 1
-3 12G4036
1
LINK STOP, TRAY 2
-4 12G4021
1
SENSOR, PHOTO
-5 12G4023
1
STOP, TRAY F
-6 12G4025
1
SPACER, L
-7 12G4022
1
GUIDE, TRAY 1
-7 12G4035
1
GUIDE, TRAY 2
-8 12G4028
1
KIT, SENSOR ACTUATOR
-9 12G4020
1
MOTOR ASM, PAPER TRAY
-10 12G4019
1
SWITCH ASM, PAPER SIZE
