7-33 Parts Catalog
4025-XXX
Assembly 16: Xerography and Development
Asm-
Index
Part
Number
Units Description
16-1 12G4069
1
SWITCH ASM, INTERLOCK
-2 12G4071
1
PLATE, CONTACT D
-3 12G4070
1
PLATE, CONTACT C
-4 12G4065
1
SENSOR ASM, TONER
-5 12G4066
1
SPRING, SENSOR
-6 12G4062
1
ROLLER, TRANSFER
-7 12G4064
1
SLIDER, EXIT
-8 12G4063
1
CONTACT ASM, TRANSFER ROLLER
-9 12G4068
1
BRACKET, CABLE
-10 12G4067
1
CONTACT ASM, CARTRIDGE
