Lexmark X820E - Page 397

7-51 Parts Catalog
4025-XXX
Assembly 25: Harness
Asm-
Index
Part
Number
Units Description
25-1 12G4108
1
CABLE ASM, HVPS
-2 12G4107
1
CABLE ASM, MOTOR
-3 12G4105
1
CABLE ASM, INTERLOCK
-4 12G4104
1
CABLE ASM, PAPER SIZE
-5 12G4103
1
CABLE ASM, REGISTRATION
-6 12G4102
1
CABLE ASM, OUTPUT
-7 12G4101
1
CABLE ASM, DUPLEX
-8 12G4100
1
CABLE ASM, BOTTOM
-9 12G4099
1
CABLE ASM, TRAY
-10 12G4098
1
CABLE ASM, TRAY 1 REAR
-11 12G4097
1
CABLE ASM, MAIN
-12 12G4106
1
CABLE ASM, DC REAR
