4. Operating AC Smart

AC Smart

4-102

5. Saving is finished. When saving is finished, [Save] button is deactivated, and when the current

information is changed, it is activated again. Click [Close] button to return to the previous screen.

Click [Close] button to

return to the previous

screen
