Specifications
380V, Heat Pump(60Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
Heating * Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
* Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Model Name Combination Unit
Independent Unit
Capacity Cooling W
kcal/h
Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Heat Exchanger
Compressor Type
Maker
Piston Displacement cm
2
/rev
Number of Revolution r.p.m
Motor Output x Number W
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor Output x Number W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm
inch
Net Weight kg
lbs
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
36 38 40
LRUN3609TR0 LRUN3809TR0 LRUN4009TR0
LRUN1209TR0 LRUN1409TR0 LRUN1609TR0
LRUH1209TR0 LRUH1209TR0 LRUH1209TR0
LRUH1209TR0 LRUH1209TR0 LRUH1209TR0
100,800 106,400 112,000
86,700 91,500 96,300
343,900 363,100 382,200
113,400 119,700 126,000
97,500 102,900 108,400
386,900 408,400 429,900
35.4 37.5 39.5
33 35 36.8
WARM GRAY WARM GRAY WARM GRAY
Louver Fin Louver Fin Louver Fin
Scroll Scroll Scroll
LG LG LG
77.87+110x5 77.87+110x5 77.87+110x5
(3472, 3500)+(3500, 3500)x2 (3472, 3500)+(3500, 3500)x2 (3472, 3500)+(3500, 3500)x2
(4309+5700)+(5700+5700)x2 (4309+5700)+(5700+5700)x2 (4309+5700)+(5700+5700)x2
Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
2325 ± 10, (2325 ± 10)x5 2325 ± 10, (2325 ± 10)x5 2325 ± 10, (2325 ± 10)x5
Propeller Fan Propeller Fan Propeller Fan
291x2+271x4 291x2+271x4 291x2+271x4
90x6 90x6 90x6
3177x6 3177x6 3177x6
Inverter Inverter Inverter
Top Top Top
Ø22.2(7/8) Ø22.2(7/8) Ø22.2(7/8)
Ø44.5(1 3/4) Ø44.5(1 3/4) Ø44.5(1 3/4)
(1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3 (1280 * 1555 * 730)x3
(50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3 (50.4 * 61.2 * 28.7)x3
300x3 300x3 300x3
661.4x3 661.4x3 661.4x3
CV 38X5C CV 38X5C CV 38X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22
L.E.V L.E.V L.E.V
3 / 380 / 60 3 / 380 / 60 3 / 380 / 60
