LG multi V PLUS Service Manual

202 Outdoor Unit
Specifications
220V, Heat Pump(60Hz)
Notes:
1. Capacities are based on the following conditions:
Cooling * Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
* Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
Heating * Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
* Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
* Interconnecting Piping Length 7.5m
* Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
HP
Combination Unit
Model Name
Independent Unit
Cooling W
kcal/h
Capacity Btu/h
Heating W
kcal/h
Btu/h
Input Cooling kW
Heating kW
Casing Color
Compressor Type
Maker
Piston Displacement cm
3
/rev
Number of Revolution r.p.m
Motor OutputxNumber kW
Starting Method
Oil Type
Oil Charge CC
Fan Type
Motor OutputxNumber W
Air Flow Rate(High) cmm
cfm
Drive
Discharge Side / Top
Pipe Connctions Liquid Pipes mm(inch)
Gas Pipes mm(inch)
Dimensions (W*H*D) mm(inch)
Net Weight kg(lbs)
Power Supply Cable mm
2
Transmission Cable mm
2
Refigerant Refigerant name
Control
Power Supply Ø / V / Hz
81012
LRUN80BT0 LRUN100BT0 LRUN120BT0
LRUN80BT0 LRUN100BT0 LRUN120BT0
22,400 28,000 33,600
19,300 24,100 28,900
76,400 95,500 114,700
25,200 31,500 37,800
21,700 27,100 32,500
86,000 107,500 129,000
7.7 9.8 11.8
7.5 9.6 11.5
WARM GRAY WARM GRAY WARM GRAY
Scroll Scroll Scroll
LG LG LG
53.5+110 53.5+110 53.5+110
3460, 3500 3460, 3500 3460, 3500
3120+6100 3120+6100 3120+6100
Direct on Line Direct on Line Direct on Line
SUNISO 4GSI SUNISO 4GSI SUNISO 4GSI
1950 ± 10, 2325 ± 10 1950 ± 10, 2325 ± 10 1950 ± 10, 2325 ± 10
Propeller Fan Propeller Fan Propeller Fan
291x2 291x2 291x2
90x2 90x2 90x2
3177x2 3177x2 3177x2
Inverter Inverter Inverter
Top Top Top
Ø12.7(1/2) Ø12.7(1/2) Ø12.7(1/2)
Ø28.58(1 1/8) Ø28.58(1 1/8) Ø28.58(1 1/8)
1280 * 1555 * 730(50.4 * 61.2 * 28.7) 1280 * 1555 * 730(50.4 * 61.2 * 28.7) 1280 * 1555 * 730(50.4 * 61.2 * 28.7)
300(661.4) 300(661.4) 300(661.4)
CV 22X5C CV 22X5C CV 22X5C
CVV-SB 1.25X2C CVV-SB 1.25X2C CVV-SB 1.25X2C
R22 R22 R22
L.E.V L.E.V L.E.V
3, 220, 60 3, 220, 60 3, 220, 60
