LG multi V PLUS

Service Manual 309
Explodede View & Replacement Parts List
PART No.
130412 BASE ASSEMBLY,WELD[INDOOR] 3041A10013A 3041A10013A 3041A10013A 3041A10013A
130911 CABINET ASSEMBLY,INDOOR 3091A10023C 3091A10023C 3091A10023C 3091A10023C
130911 CABINET ASSEMBLY,INDOOR 3091A10023D 3091A10023D 3091A10023D 3091A10023D
135314 GRILLE,INLET 3530A10065A 3530A10065A 3530A10065A 3530A10065A
137211 PANEL ASSY,FRONT(INDOOR) 3721A10021C 3721A10021A 3721A10021C 3721A10021A
135511 COVER 3550A20034A 3550A20034A 3550A20034A 3550A20034A
135802 DOOR 3580A20005A 3580A20005A 3580A20005A 3580A20005A
140570 LOCKER 4056A20001A 4056A20001A 4056A20001A 4056A20001A
146811 MOTOR ASSEMBLY,STEP 4681AP2968D 4681AP2968D 4681AP2968D 4681AP2968D
152312 FILTER ASSY,AIR CLEANER 5231A10005A 5231A10005A 5231A10005A 5231A10005A
152510 DRAIN ASSY,TUBE 5251A20002A 5251A20002A 5251A20002A 5251A20002A
152510 HOSE ASSEMBLY,DRAIN 5251AP2984A 5251AP2984A 5251AP2984A 5251AP2984A
158591 PUMP ASSEMBLY,WATER 5859A20001H 5859A20001H 5859A20001H 5859A20001H
249941 CONTROL BOX,INDOOR 4994A10014A 4994A10014A 4994A10014A 4994A10014A
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10083F 4995A10083C 4995A10083G 4995A10083D
263230 THERMISTOR ASSEMBLY 6323A30002B 6323A30002B 6323A30002B 6323A30002B
263230 THERMISTOR ASSEMBLY 6323A30004C 6323A30004C 6323A30004C 6323A30004C
263230 THERMISTOR ASSEMBLY 6323AQ3226R 6323AQ3226R 6323AQ3226R 6323AQ3226R
266012 SWITCH ASSY,FLOAT 6601A20001F 6601A20001F 6601A20001F 6601A20001F
267110 REMOTE CONTROLLER ASSEMBLY 6711A20081M 6711A20081J 6711A20081M 6711A20081J
268712 PWB(PCB) ASSY,DISPLAY 6871A20096C 6871A20096C 6871A20096C 6871A20096C
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10187N 6871A10187L 6871A10187P 6871A10187M
330870 DRAIN PAN ASSEMBLY 3087A10002A 3087A10002A 3087A10002A 3087A10002A
346810 MOTOR ASSEMBLY,SINGLE 4681AC2026E 4681AC2026E 4681AC2026D 4681AC2026D
349600 MOUNT,MOTOR 4960A20010A 4960A20010A 4960A20010A 4960A20010A
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10335B 5211A10335B 5211A10335A 5211A10335A
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20241N 5211A20241N 5211A20241P 5211A20241P
354211 EVAPORATOR ASSY,BENDING 5421A10006A 5421A10006A 5421A10006B 5421A10006B
359012 FAN,TURBO 5900A10004A 5900A10004A 5900A10004A 5900A10004A
435310 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10059A 3531A10059A 3531A10059A 3531A10059A
W0CZZ CAPACITOR,DRAWING 3H00660N 3H00660N 3H00660N 3H00660N
W6640 TERMINAL BLOCK 6640W3A009B 6640W3A009B 6640W3A009B 6640W3A009B
LOCATION
No.
DESCRIPTION
REMARK
LRNV126TEA0 LRNN126TEA0 LRNV186TEA0 LRNN186TEA0
