LG multi V PLUS

310 Indoor Unit
Explodede View & Replacement Parts List
PART No.
LRNV182TEC0
130412 BASE ASSEMBLY,WELD[INDOOR] 3041A10013A
130911 CABINET ASSEMBLY,INDOOR 3091A10023C
130911 CABINET ASSEMBLY,INDOOR 3091A10023D
135314 GRILLE,INLET 3530A10065A
135511 COVER 3550A20034A
135802 DOOR 3580A20005A
137211 PANEL ASSEMBLY,FRONT(INDOOR) 3721A10021S
140570 LOCKER 4056A20001A
146811 MOTOR ASSEMBLY,STEP 4681AP2968D
152312 FILTER ASSY,AIR CLEANER 5231A10005A
152510 DRAIN ASSY,TUBE 5251A20002A
152510 HOSE ASSEMBLY,DRAIN 5251AP2984A
158591 PUMP ASSEMBLY,WATER 5859A20001H
159830 AIR CLEANER ASSEMBLY 5983A10002C
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A10083E
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20168B
263230 THERMISTOR ASSEMBLY 6323A30002B
263230 THERMISTOR ASSEMBLY 6323A30004C
263230 THERMISTOR ASSEMBLY 6323AQ3226R
266012 SWITCH ASSY,FLOAT 6601A20001F
266090 H.V ASSEMBLY 6609A20005C
267110 REMOTE CONTROLLER ASSEMBLY 6711A10002Q
268712 PWB(PCB) ASSY,DISPLAY 6871A20096C
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10148U
330870 DRAIN PAN ASSEMBLY 3087A10002A
346810 MOTOR ASSEMBLY,SINGLE 4681AC2026D
349600 MOUNT,MOTOR 4960A20010A
352115 TUBE ASSEMBLY,EVAPORATOR IN 5211A10335A
352118 TUBE ASSEMBLY,MENIFOLD(INDOOR) 5211A20241P
354211 EVAPORATOR ASSY,BENDING 5421A10006B
359012 FAN,TURBO 5900A10004A
435310 GRILLE ASSEMBLY,FRONT(INDOOR) 3531A10059A
W0CZZ CAPACITOR,DRAWING 3H00660N
W6640 TERMINAL BLOCK 6640W3A009B
LOCATION No. DESCRIPTION
REMARK
