LG multi V PLUS

Service Manual 327
Exploded View & Replacement Parts List
LRNN076BTG0
PART No.
LRNN096BTG0 LRNN126BTG0
152302 FILTER(MECH),A/C 5230A30001Q 5230A30001Q 5230A30001Q
158580 PUMP ASSEMBLY,WATER 5859A10005A 5859A10005A 5859A10005A
237203 PANEL ASSEMBLY,UPPER 3721A20150B 3721A20150B 3721A20150B
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20514C 4995A20514D 4995A20514E
263230 THERMISTOR ASSEMBLY 6323A30004D 6323A30004D 6323A30004D
263230 THERMISTOR ASSEMBLY 6323AQ3226G 6323AQ3226G 6323AQ3226G
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W 6323AQ3226W
267110 REMOTE CONTROLLER ASSEMBLY 6711A20043D 6711A20043D 6711A20043D
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10217F 6871A10217G 6871A10217H
330870 DRAIN PAN ASSEMBLY 3087A10015C 3087A10015C 3087A10015C
336610 HOUSING ASSEMBLY (MECH) 3661A20025A 3661A20025A 3661A20025A
346810 MOTOR ASSEMBLY,INDOOR 4681A10022B 4681A10022B 4681A10022B
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A10418E 5211A10418E 5211A10418E
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20153B 5421A20153B 5421A20153B
359012 FAN ASSEMBLY,BLOWER 5901A20030A 5901A20030A 5901A20030A
55211G TUBE ASSEMBLY,EXPANSION 5211A10508A 5211A10508A 5211A10508A
WOCZZ CAPACITOR,DRAWING 3A02157H 3A02157H 3A02157H
LOCATION No. DESCRIPTION
REMARK
