LG multi V PLUS

328 Indoor Unit
Exploded View & Replacement Parts List
LRNV092BTQ0 LRNV122BTQ0
PART No.
152302 FILTER(MECH),A/C 5230A30001Q 5230A30001Q
158580 PUMP ASSEMBLY,WATER 5859A10005A 5859A10005A
159830 AIR CLEANER ASSEMBLY 5983A10003A 5983A10002A
237203 PANEL ASSEMBLY,UPPER 3721A20150B 3721A20150B
249951 CONTROL BOX ASSEMBLY,INDOOR 4995A20338X 4995A20338W
263230 THERMISTOR ASSEMBLY 6323A30004D 6323A30004D
263230 THERMISTOR ASSEMBLY 6323AQ3226G 6323AQ3226G
263230 THERMISTOR ASSEMBLY 6323AQ3226W 6323AQ3226W
266090 H.V ASSEMBLY 6609A20005G 6609A20005G
267110 REMOTE CONTROLLER ASSEMBLY 6711A10008C 6711A10008C
268714 PWB(PCB) ASSEMBLY,MAIN 6871A10166P 6871A10166Q
330870 DRAIN PAN ASSEMBLY 3087A10015C 3087A10015C
336610 HOUSING ASSEMBLY (MECH) 3661A20025A 3661A20025A
346810 MOTOR ASSEMBLY,INDOOR 4681A10022B 4681A10022B
352116 TUBE ASSEMBLY,EVAPORATOR OUT 5211A10418E 5211A10418E
354210 EVAPORATOR ASSEMBLY,FIRST 5421A20153B 5421A20153B
359012 FAN ASSEMBLY,BLOWER 5901A20030A 5901A20030A
55211G TUBE ASSEMBLY,EXPANSION 5211A10508A 5211A10508A
WOCZZ CAPACITOR,DRAWING 3A02157H 3A02157H
LOCATION No. DESCRIPTION
REMARK
