38 Indoor Unit
Specifications
Heat Pump (50Hz)
Notes:-
1. Capacities are based on the following conditions:
Cooling • Indoor temp. 27°C[80.6°F]DB/ 19°C[66.2°F]WB
• Outdoor temp. 35°C[95°F]DB/ 24°C[75.2°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
Heating • Indoor temp. 20°C[68°F]DB/ 15°C[59°F]WB
• Outdoor temp. 7°C[44.6°F]DB/ 6°C[42.8°F]WB
• Interconnecting Piping Length 7.5m
• Level Difference of Zero
2. Capacities are net capacities
3. Due to our policy of innovation some specifications may be changed without notification
4. L.E.V.:Linear Expansion Valve
Conversion Formula
Kcal/h= kW x 860
Btu/h = kW x 3412
cfm = m
3
/min x 35.3
Model Unit
W
Cooling Capacity kcal/h
Btu/h
W
Heating Capacity kcal/h
Btu/h
Casing
Body
mm
Dimensions (W*H*D)
inch
Front Panel
mm
inch
Coil
Rows x Columns x FPI
Face Area m
2
Type
Motor Output W
Running Current A
Fan Air Flow Rate(H/M/L) cmm
cfm
Drive
Speed control
Temperature Control
Sound Absorbing Thermal Insulation Material
Safety Device
Liquid Side mm(inch)
Pipe Connections
Gas Side mm(inch)
Drain Pipe(OD)
mm
Net Weight kg(lbs)
Noise Level
(Sound Press, 1.5m, H/M/L)
dBA±3
Power Supply Ø / V / Hz
Refrigerant Control
Power cable mm
2
Transmission cable mm
2
Panel Color
Stuffing Quantity Without S/parts
20/40ft
LRNN246TDA(C)0 LRNN286TDA(C)0 LRNN366TDA(C)0
7,000 8,200 10,600
6,019 7,052 9,116
23,885 27,995 36,168
7,875 9,225 11,925
6,771 7,934 10,253
26,870 31,494 40,689
Galvanized Steel Plate Galvanized Steel Plate Galvanized Steel Plate
840*840*290 840*840*290 840*840*290
33.0*33.0*11.4 33.0*33.0*11.4 33.0*33.0*11.4
950*950*30 950*950*30 950*950*30
37.4*37.4*1.2 37.4*37.4*1.2 37.4*37.4*1.2
2*12*21 2*12*21 2*12*21
2*0.26 2*0.26 2*0.26
Turbo Fan Turbo Fan Turbo Fan
60 60 60
0.80 0.80 1.10
19/17/15 23/21/18 26/24/22
671/601/530 813/742/636 919/848/777
Direct Direct Direct
Phase Control Phase Control Phase Control
Microprocessor, Thermostat for cooling and heating Microprocessor, Thermostat for cooling and heating Microprocessor, Thermostat for cooling and heating
Foamed polystrene Foamed polystrene Foamed polystrene
Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor Fuse, Thermal Fuse for Fan Motor
Ø9.52(3/8) Ø9.52(3/8) Ø9.52(3/8)
Ø15.88(5/8) Ø15.88(5/8) Ø19.05(3/4)
32.0 32.0 32.0
32(70.5) 32(70.5) 32(70.5)
41/38/36 42/40/38 43/41/39
1 / 220 ~ 240 / 50 1 / 220 ~ 240 / 50 1 / 220 ~ 240 / 50
LEV LEV LEV
CV2.0 X 3C CV2.0 X 3C CV2.0 X 3C
CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C CVV-SB 1.25 X 2C
White White White
72/144 72/144 72/144
