LG SV-iS5 User Manual

4
460/480 V Class (1 ~ 30HP)
Model Number
(SV xxx iS5 - 4)
008 015 022 037 055 075 110 150 185 220
HP 1 2 3 5 7.5 10 15 20 25 30 Motor
Rating
1
kW 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22
Capacity
2
[kVA] 1.9 3.0 4.5 6.1 9.1 12.2 18.3 22.9 29.7 34.3
FLA [A] 2.5 4 6 8 12 16 24 30 39 45
Frequency 0 ~ 400 Hz (Sensorless Vector Control: 0 ~ 300Hz, Sensored Vector Control: 0 ~ 120 Hz)
Output
Ratings
Voltage 380 ~ 460 V, 380 ~ 480 V
3
Voltage 3 Phase, 380 ~ 460 V (± 10 %), 380 ~ 480 V (± 10 %) (Special type available from ‘2004)
5
Input
Ratings
Frequency 50 ~ 60 Hz (±5 %)
Braking Circuit
On Board On Board
Optional
(DB Resistor)
Optional (DB Resistor)
Max. Braking
Torque
100% 100% 100%
Max. Continuous
Baking Time
5 seconds 5 seconds 15 seconds
Dynamic
Braking
4
Max. Duty 3 % ED 2 % ED
20%
Continuous
10 % ED
Weight [kg] 4.7 4.7 4.8 4.9 7.7 7.7
13.9 14.4 20 20
460/480 V Class (40~100HP)
Model Number
(SV xxx iS5 - 4)
300 370 450 550 750
HP 40 50 60 75 100 Motor
Rating
1
kW 30 37 45 55 75
Capacity
2
[kVA] 45 56 68 82 100
FLA [A] 61 75 91 110 152
Frequency 0 ~ 400 Hz (Sensorless Vector Control: 0 ~ 300Hz, Sensored Vector Control: 0 ~ 120 Hz)
Output
Ratings
Voltage 380 ~ 460 V, 380 ~ 480 V
3
Voltage 3 Phase, 380 ~ 460 V (± 10 %), 380 ~ 480 V(± 10 %) (Special type available from ‘2004)
6
Input
Ratings Frequency 50 ~ 60 Hz (±5 %)
Braking Circuit Optional (Braking Unit, Resistor)
Max. Braking
Torque
Max. Continuous
Baking Time
Dynamic
Braking
4
Max. Duty
20%, Continuous
Weight [kg] 45 45 63 63 68
5
When applying input voltage of 507~528 V range, derate the load 10%. For example, when applying 507 V to 5.5kW inverters (rated
current 12A), the max. rated output current would be 10.8A, calculated by multiplying 12A by 0.9 (90%).
6
Same as above.
