Chapter 5 - Parameter List
75
Keypad Display Setting Range
Code
Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
COM-31
Output 1 Output 1 31 0000-57FF(HEX) 000A(HEX)
Yes
COM-32
Output 2 Output 2 32 0000-57FF(HEX) 000E(HEX)
Yes
COM-33
Output 3 Output 3 33 0000-57FF(HEX) 000F(HEX)
Yes
COM-34
Output 4 Output 4 34 0000-57FF(HEX) 0000(HEX)
Yes
COM-35
Output 5 Output 5 35 0000-57FF(HEX) 0000(HEX)
Yes
COM-36
Output 6 Output 6 36 0000-57FF(HEX) 0000(HEX)
Yes
COM-37
Output 7 Output 7 37 0000-57FF(HEX) 0000(HEX)
Yes
COM-38
Output 8 Output 8 38 0000-57FF(HEX) 0000(HEX)
Yes
COM-40
Input Number Input Num 40 0 to 8 1 2 Yes
COM-41
Input 1 Input 1 41 0000-57FF(HEX) 0005(HEX)
Yes
COM-42
Input 2 Input 2 42 0000-57FF(HEX) 0006(HEX)
Yes
COM-43
Input 3 Input 3 43 0000-57FF(HEX) 0000(HEX)
Yes
COM-44
Input 4 Input 4 44 0000-57FF(HEX) 0000(HEX)
Yes
COM-45
Input 5 Input 5 45 0000-57FF(HEX) 0000(HEX)
Yes
COM-46
Input 6 Input 6 46 0000-57FF(HEX) 0000(HEX)
Yes
COM-47
Input 7 Input 7 47 0000-57FF(HEX) 0000(HEX)
Yes
COM-48
Input 8 Input 8 48 0000-57FF(HEX) 0000(HEX)
Yes
COM-52
ModBus Option Selection
ModBus Mode
52 ModBus RTU
ModBus
RTU
Yes
COM-99
Return Code Not displayed
99 Not available
[PROG/ENT]
or
[SHIFT/ESC]
- 1 Yes
5.7 Application Group [APP]
Keypad Display Setting Range
Code
Description
LCD 7-Segment
LCD 7-Segment
Units
Factory
Default
Adj.
During
Run
Page
APP-00
Jump to Desired Code #
Jump code Not displayed
0 to 99 Not available
1 1 Yes
145
None 0
Traverse 1
MMC 2
APP-01
Application Mode
Selection
App Mode 01
DRAW 3
- None No 145
APP-02
28
Traverse Amplitude Trv. Amp 02 0.0 to 20.0 [%] 0.1
0.0 [%] Yes
146
APP-03
Traverse Scramble
Amplitude
Trv. Scr 03 0.0 to 50.0 [%] 0.1
0.0 [%] Yes
146
APP-04
Traverse Accel Time Trv Acc Time 04 0.1 to 6000 [sec] 0.1
2.0 [sec]
Yes
146
APP-05
Traverse Decel Time Trv Dec Time 05 0.1 to 6000 [sec] 0.1
3.0 [sec]
Yes
146
APP-06
Traverse Offset (Hi)
Setting
Trv Off Hi 06 0.0 to 20.0 [%] 0.1
0.0 [%] Yes
147
APP-07
Traverse Offset (Lo)
Setting
Trv Off Lo 07 0.0 to 20.0 [%] 0.1
0.0 [%] Yes
147
APP-08
29
Running Auxiliary Motor
Number Display
Aux Mot Run 08 - - - - 147
28
Code APP-02 through APP-07 appears only when APP-01 is set to ‘Traverse’.
29
Code APP-08 through APP-31 appears only when APP-01 is set to ‘MMC’.
