Chapter 3 – Function Settings
45
3) Auto sequence operation
If I/O-50 [Auto (Sequence) Operation selection] is set to 1 {Auto-A} or 2 {Auto-B}, up to 5 sequences can be set with
max of 8 steps (speed) in each sequence. Therefore, max 40 operating steps can be made. Two different types of auto
sequence (A, B) operation are available.
Parameter Name Code Description
Auto operation setting
I/O-50 ~ 84 Sets 8 steps and 5 sequences (Max).
4) 2
nd
motor operation
2
nd
function setting is required to run the two motors by one inverter by exchange. If the terminal defined for 2
nd
function
signal input is turned ON, 2
nd
motor operation is valid.
Parameter Name Code Description
Multi-function input
terminals setting
I/O-12 ~14
EXT2 ~ 4
2
nd
motor operation is available with Multi-function input
terminals P1 ~ P3 or P4 ~ 6 set to 7 {2
nd
Func}.
Parameter setting for
2
nd
motor operation
FU2-81 ~ FU2-90
Setting parameters necessary to operate 2
nd
motor such
as base freq., Accel/Decl time, Stall.
5) Energy-saving operation
FU1-39 [Energy Save Level] tunes the inverter output voltage to minimize the inverter output voltage during during
constant speed operation. Appropriate for energy-saving applications such as fan, pump and HVAC.
