Chapter 7 - Options
161
7.3 Sub-C Board (Isolated)
7.3.1 Board Configuration
3P
230/460 V
50/60 Hz
IM
U
V
W
E
R
S
T
FX
RX
BX
RST
JOG
P2
P3
+
FM
5G
30A
30B
30C
AXA
AXC
Output freq
analog meter
(0-10V, 1mA)
*2
P1
Fault output relay
Less than AC 250V, 1A
Less than DC 30V, 1A
VR
V1
I
5G
0
-
10V(1 kohm)
*3
Maximum
current thru
PC: 5mA
CM
NFB MC
24 V
AM2
AM1
P4
P5
P6
Q1
EXTG
VR
V2
GND
XCEL-L
Multi-function
input
Open collector
Multi-function
input (Less than
25V, 50mA)
FDT-1
Analog meter output 1
(0-10V, 1mA)
Sub- C
Board
F
M
CM
FWD Run/Stop
REV Run/Stop
Fault reset
JOG
Multi-function input 1
Common Terminal
Multi-function input 2
Multi-function input 3
Emergency brake
Note) 1. : Main circuit : Control circuit
2. Output voltage is adjustable up to 12V
3. Three types of External speed signal input available
(V, I, V+I, Refer to Parameter list and description for more details)
.
4 - 20mA (250 ohm)
Speed signal input
Common
terminal for
VR,V1, I
Power supply for
speed signal
(+12V 10mA)
Speed signal input
Factory setting:
Multi-speed
input
(Speed-L,M,H)
Potentiometer
1kohm, 1/2W
Potentiometer
1kohm, 1/2W
Speed signal input
Analog meter output 2
(0-10V, 1mA)
XCEL-M
XCEL-H
Common terminal
for P4-6
Common terminal
for Q1
Multi-function output relay
Less than AC 250V, 1A
Less than DC 30V, 1A
Factory setting:'Run'
