Chapter 5 - Parameter List
76
Keypad Display Setting Range
Code
Description
LCD 7-Segment
Starting Aux. Motor
Selection
Starting Aux 09 1 to 4 1 1 Yes
Operation Time Display
on Auto Change
Auto Op Time
Start Frequency of Aux.
Motor 1
Start freq 1 11 0 to FU1-20 0.01
Start Frequency of Aux.
Motor 2
Start freq 2 12 0 to FU1-20 0.01
Start Frequency of Aux.
Motor 3
Start freq 3 13 0 to FU1-20 0.01
Start Frequency of Aux.
Motor 4
Start freq 4 14 0 to FU1-20 0.01
Stop Frequency of Aux.
Motor 1
Stop freq 1 15 0 to FU1-20 0.01
Stop Frequency of Aux.
Motor 2
Stop freq 2 16 0 to FU1-20 0.01
Stop Frequency of Aux.
Motor 3
Stop freq 3 17 0 to FU1-20 0.01
Stop Frequency of Aux.
Motor 4
Stop freq 4 18 0 to FU1-20 0.01
Delay Time before
Operating Aux Motor
Aux start DT 19 0 to 9999 [sec] 0.1
Delay Time before
Stopping Aux Motor
Aux stop DT 20 0 to 9999 [sec] 0.1
The Number of Aux Motor Nbr Aux’s 21 0 to 4 1 4 Yes
PID Bypass Selection Regul Bypass
Sleep Delay Time Sleep Delay 23 0 to 9999 [sec] 0.1
Sleep Frequency Sleep Freq 24 0 to FU1-20 0.01
Wake-Up Level WakeUp Level
25 0 to 100 [%] 1 35.0 [%]
Auto Change Mode
Selection
AutoCh-Mode
Auto Change Time AutoEx-intv 27 00:00 to 99:00 00:01
Auto Change Level AutoEx-level 28 0 to 100 [%] 0.1
Inter-Lock Selection Inter-lock 29
Yes 1
- No Yes
Feedback Freq/
Percentage Display
Fbk/PER 30 [Hz] / [%] - 150
Actual Value Display Prs 31 [Bar]/[Pa] - - - - 151
Scale Disp 32 0 to 50000 - 1000 Yes
None 0
V1_Draw 1
I_Draw 2
APP-33
30
Draw Mode Selection Draw Mode 33
V2_Draw 3
- None Yes
Draw Size Setting DrawPerc 34 0 to 150 [%] 0.1
30
Code APP-32 through APP-33 appears only when APP-01 is set to ‘Draw’.
