Chapter 7 - Options
154
The following table shows the Sub-Board Selection Guide according to Functions.
Sub-Board Type
Code
Function Description
SUB-A Board SUB-B Board SUB-C Board
EXT-02
Multi-Function Input Terminal ‘P4’
√ √
EXT-03
Multi-Function Input Terminal ‘P5’
√ √
EXT-04
Multi-Function Input Terminal ‘P6’
√ √
EXT-05
V2 Mode Selection
√ √
EXT-06
Filtering Time Constant for V2 Input Signal
√ √
EXT-07
V2 Input Minimum Voltage
√ √
EXT-08
Frequency Corresponding to V2 Input Minimum Voltage
√ √
EXT-09
V2 Input Maximum Voltage
√ √
EXT-10
Frequency Corresponding to V2 Input Maximum Voltage
√ √
EXT-14
Usage for Pulse Input Signal
√
EXT-15
Pulse Input Signal Selection
√
EXT-16
Encoder Pulse Selection
√
EXT-17
Filtering Time Constant for Pulse Input Signal
√
EXT-18
Pulse Input Minimum Frequency
√
EXT-19
Frequency Output corresponding to Pulse Input Minimum
Frequency
√
EXT-20
Pulse Input Maximum Frequency
√
EXT-21
Frequency Output corresponding to Pulse Input Maximum
Frequency
√
EXT-22
P-Gain for PG Option
√
EXT-23
I-Gain for PG Option
√
EXT-24
Slip Frequency for PG Option
√
EXT-25
P-Gain for (Sensored) Vector_SPD
EXT-26
I-Gain for (Sensored) Vector_SPD
EXT-27
Forward Torque Limit
EXT-28
Reverse Torque Limit
EXT-30
Multi-function Output Terminal ‘Q1’
√ √
EXT-31
Multi-function Output Terminal ‘Q2’
√
EXT-32
Multi-function Output Terminal ‘Q3’
√
EXT-34
LM (Load Meter) Output Selection
√
EXT-35
LM Output Adjustment
√
EXT-40
AM1 (Analog Meter 1) Output Selection
√
EXT-41
AM1 Output Adjustment
√
EXT-42
AM2 (Analog Meter 2) Output Selection
√
EXT-43
AM2 Output Adjustment
√
