Trackit Mk3 User Manual
78
Tr a ck it Bluet oot h Modu le Specificat ions
N ot e : Lifelines reserves t he right to change product specifications at any t im e wit hout not ice. This
is in- line with the com pany’s policy of continual product developm ent .
There are several versions of t he Bluetoot h Module: Type 1 is designed to be connect ed t o t he
Trackit Mk1 or Mk1+ and Type 2 t he Trackit Mk2. These have a 9- pin and 15- pin m icro-D con-
nector fitted respect ively. Additionally, t here are two versions of t he internal Bluetoot h circuitry:
Original ( OEMSPA33i) and 3rd Generat ion ( OEMSPA332i) and t he latest 4
th
Generat ion ( OBS433i).
The 3
rd
and 4
th
generations are significant ly sm aller and lower power consum pt ion t han t he Origi-
nal. The 3
rd
Generation was int roduced in May 2006, t he 4
th
in January 2012.
These versions are ident ified as follows:
1. Original Type 1 for Trackit Mk1. Part num ber m arked on cable 6738- 000. Lifelines part 1048.
2. Original Type 2 for Trackit Mk2. Part num ber m arked on cable 6738- 100. Lifelines part 1121.
3. 3rd Generat ion Type 1 for Trackit Mk1. Part num ber m arked on cable 6738- 200. Lifelines part
1048.
4. 3rd Generat ion Type 2 for Trackit Mk2. Part num ber m arked on cable 6738- 300. Lifelines part
1121.
5. 3
rd
Generation I nternal for Trackit Mk2 and Mk3 only.
6. 4
th
Generation Internal for Trackit Mk3 only.
N ot e t hat t he 4
t h
Gen e r a t ion m odule ha s a m u ch im prove d r a nge , re fer be low .
Para m et er Da t a
Origina l ( OEMSPA3 3 i)
Bluetoot h Module m anufact urer : connectBlue AB, Sweden
Bluetoot h radio : I nfineon/ Ericsson PBD 313 02 (MI RI AN)
Bluet oot h base band cont roller : I nfineon/ Ericsson PBM 990 90 ( BLI NK)
RF out put power : Class 1, m in –28dBm , m ax + 16dBm
Note : 0 dBm = 1 m W, 20 dBm = 100 m W
Receive sensit ive level : - 80dBm (0.1% BER)
Receive input level (m ax) : Max + 15 dBm
Output frequency : 2.402 –2.480 GHz, I SM band.
Point to m ulti-point operat ion : Yes
Bluet ooth st ack : Embedded host st ack
Bluetoot h qualificat ion : 1.1
3 r d Gene ra t ion ( OEMSPA3 3 2 i)
Bluetoot h Module m anufact urer : connectBlue AB, Sweden
Bluetoot h radio : Philips BGB203
Bluetoot h base band cont roller : Philips BGB203
RF out put power : Class 1, m in –28dBm , m ax + 16.9dBm (49m W)
Note : 0 dBm = 1 m W, 20 dBm = 100 m W
Receive sensit ive level : - 89dBm (0.1% BER)
Receive input level (m ax) : Max + 16dBm
Output frequency : 2.402 –2.480 GHz, I SM band.
Point to m ulti-point operat ion : Yes
Bluet ooth st ack : Embedded host st ack
Bluetoot h qualificat ion : 2.0
4 t h Gene ra t ion ( OBS4 3 3 i)
Bluetoot h Module m anufact urer : connectBlue AB, Sweden
Bluetoot h radio : ST- Ericsson STLC2500DB
Bluetoot h base band cont roller : ST Microelectronics STM32F10x
