Trackit Mk3 User Manual
91
Guidance and Manufacturer’s Declaration
Electromagnetic Emissions
EN 60601-1-2
The Trackit Mk3 is int ended for use in the electrom agnet ic environm ent specified below. The cus-
tom er or user of the Trackit should assure that it is used in such an environm ent .
Em ission s Te st
Com plia n ce
Ele ct r om ag net ic En vir onm e nt Guidance
RF em issions
CISPR11/ EN5501 1
Group 1 The Track it uses RF energy only for it s int ernal funct ion. Ther efor e, its
RF em issions ar e very low and are not likely t o cause any interference
in near by elect r on ic equipment .
RF em issions
CISPR11/ EN5501 1
Class B Th e Tr ack it is su it ab le for use in all est ablish m en t s, includ ing dom est ic
est ablishm ent s and those dir ect ly connected t o t he pu b lic low v oltage
power supply net wor k t hat supplies buildings used for dom est ic pur-
poses.
Har m onic em ission s
EN 61000-3-2
Class A
Volt age fluct u at ions/
Flicker em ission s
EN 61000-3-3
Com plies
I m m u n ity Te st EN 6 0 6 0 1 - 1 - 2
Te st Le vel
Com plia n ce Leve l Ele ct r om ag net ic En vir onm e nt Guidance
Elect rost at ic dischar ges
(ESD)
EN 61000-4-2
+ / - 6 kV: Contact
+ / - 8 kV: Air
+ / - 6 kV: Contact
+ / - 8 kV: Air
Floor s shou ld be wood, concrete or ceram ic
tile. I f floors are covered wit h synthet ic ma-
t erial, the relat ive hum idit y should be at least
30%
Elect r ical fast Tr ansi-
ent s/ bur st
EN 61000-4-4
+ / - 2 kV: AC m ains
+ / - 1 kV: Signal lines
+ / - 2 kV: AC m ains
+ / - 1 kV: Signal lines
Mains power sh ould be t h at of a t ypical com -
m er cial an d/ or h osp it al en v iron m ent
Surge
EN 61000- 4 - 5
+ / - 2 kV: Com m on m ode
+ / - 1 k V: Differ ent ial
m ode
+ / - 2 kV: Com m on
m ode
+ / - 1 k V: Differ ent ial
m ode
Mains power sh ould be t h at of a t ypical com -
m er cial an d/ or h osp it al en v iron m ent
Volt age dips, sh ort in-
terrupt ions and volt age
variat ions on power
supply input lines
EN 61000-4-11
< 5% 230 V
(> 95% dip in 230 V) for
0.5 cycle
40% 230 V
(60% dip in 230 V)
for 5 cycles
70% 230 V
(30% dip in 230 V)
for 25 cycles
< 5% 230 V
(> 95% dip in 230 V) for
5 sec
< 5% 230 V
(> 95% dip in 230 V)
for 0 . 5 cy cle
40% 230 V
(60% dip in 230 V)
for 5 cycles
70% 230 V
(30% dip in 230 V)
for 25 cycles
< 5% 230 V
(> 95% dip in 230 V)
for 5 sec
Mains power sh ould be t h at of a t ypical com -
m er cial and/ or hospit al environ m en t . I f t he
user of the Trackit requires cont inued oper a-
t ion du r ing p ower m ains int er r u pt ion s, it is
recom m ended t hat t he Trackit be power ed
from an un int errupt ible power supply or a
batt ery
Power fr equency
(50/ 60 Hz) m agnet ic
field
EN 61000-4-8
3 A/ m 3 A/ m Power frequency m agnet ic fields should be at
levels ch ar
acterist ic of a typical location in a
t y p ical com m er cial and/ or h osp it al env ir on -
m en t
