Trackit Mk3 User Manual
92
I m m u n ity Te st EN 6 0 6 0 1 Test Level Com plia n ce Le vel Ele ct r om ag net ic En vir onm e nt Guidance
Por t able and m obile RF com m un icat ion s
equipm ent should be u sed no closer t o an y
part of the Trackit, including cables t han t he
recom m ended separat ion distance calcu lated
from the equat ion applicable t o t h e frequency
of t he t ransm itter.
Recom m e nde d sepa r a t ion dist ance
RF Com m on mode/
Conducted Suscept ibilit y
EN 61000-4-6
3 Vrm s
150 kHz t o 80 MHz
( a) 0.78 Vr m s :
150 – 250 kHz
( b) 3 Vrm s :
0.25 – 35 MHz
( c) 1 Vr m s :
35 – 80 MHz
d= 4.5 √P
d= 1.2 √P
d= 3.5 √P
Note: using unsh ielded input leads
c
Radiat ed RF Elect r om ag-
net ic Fields
EN 61000-4-3
3 V/ m
80 MHz t o 2.5 GHz
(a) 0.15 V/ m :
80 – 130 MHz
(b) 0.5 V/ m :
130 – 309 MHz
(c) 1 V/ m :
309 – 2500 MHz
d= 23.3 √P : 80 MHz t o 130 MHz
d= 7 √P : 130 MHz t o 309 MHz
d= 3.5 √P : 309 MHz t o 800 MHz
d= 7 √P : 800 MHz t o 2.5 GHz
Note: using unsh ielded input leads
d
Where P is t he m ax im um out put power r at ing
of the tran sm it t er in wat t s (W) accor ding t o
the manufact urer and d is t he recom m ended
separation dist ance in m et ers (m ).
Field strengt hs from fixed RF tran sm it t er s, as
determ ined by an electrom agnetic sit e sur -
vey
a
, should be less t han t he com plian ce level
in each frequency range
b
.
I nterfer ence m ay occur in the vicinit y of equip-
m en t m ar ked w it h t he following sy m bol:
NOTE 1. At 80 MHz and 800 MHz, the higher frequency range applies.
NOTE 2. These guidelines may not apply in all situat ions. Elect r om agnet ic pr opagat ion is affected by absorpt ion and reflect ion
fr om st r u ctures, object s and people.
