2.3 Attachment with wall profiles only
The lift is normally delivered almost fully assembled. The two wall profiles need to be fitted to
the adjoining wall to ensure a stable performance.
Approach the lift to the wall and place the wall profiles from the top level. Use service mode
(see chapter 5) to run the lift to top position.
The length of the wall profiles must be elevation height +1100 mm,
and you should always have 10 mm of clearance in the bottom
between the wall profiles and the floor.
