1. Unpackning and moving the EasyLift
1.1 Definition
In order to simplify the reading of this manual, or any conversation with us, it is important to
set some basic definitions in place. The EasyLift is a lifting platform capable of transferring a
wheelchair or disabled people between two levels (max. 1250 mm).
In this manual “EasyLift lifting platform” will be mentioned as “lift”.
The lift can be supplied with doors or automatic ramp/roll-off protection. As an option it can
be equipped with a Vertical Safety Barrier. Also as an option the doors on EasyLift 1100 can be
supplied with locks (indoor version only).
Right-hand side of the lift
A: Primary Master Actuator
B: Primary Slave Actuator
C: Primary Control Board
(jumpers are on this side)
Left-hand side of the lift
D: Secondary Master Actuator
E: Secondary Slave Actuator
F: Secondary Control Board
G: RH side and LH side wall profiles
H: Automatic ramp
(can also be a door).
