3.9 Auto Return Function
Go to section 5.2 about the Liftup Service Tool to learn about the Auto return function.
3.10 Calibration
In the case of:
• Exit Service Mode
• Release of emergency button when mains is OFF
• Reset of Control Board
• Programming of Lift with Liftup Service Tool
the lift will lose its position, it will then need calibration before it can move normally again. Any
activation of call station/onboard buttons will make the lift go down to lower position. During
this movement some actuators can be faster than others to arrive at lower position
- this is normal.
Once all four actuators are “at zero” (see picture below taken from Liftup Service Tool) all four
actuators will show a green light and a “0” at Position. Once this is done, the lift can move
normally again.
