5.3 Setting lifting height (virtual top stop) by service mode
When the system is in service mode, it is possible to set the lifting height of the lift.
A. Set the system into service mode (see chapter 6).
B. Move the lift to the lower level (at this moment the lift is not calibrated, it will therefore
move with low speed). If the lift is already down, you will need to move it up about 10
cm and then down again.
C. Push the “up” button (on call stations or on the lift), until the desired level is reached
(the travel speed is now quicker, the lift is calibrated).
D. To record the new lifting height, push the emergency button (you will still stay in service
mode), and push the “up” button on the platform for one second, you will hear “a
validation sound”.
E. Come out of the service mode (see chapter 6).
IMPORTANT! After programming the system must be calibrated by pushing the
“lift down” button. Run the lift all the way down.
