liftup EasyLift - Attachment with Wall Profiles and Door; Easylift 800;900

INSTALLATION & SERVICE MANUAL – EASYLIFT – UK VERS 1.5
Liftup A/S Hagensvej 21| DK-9530 Støvring | Denmark | T: +45 96 86 30 20 | M: support@liftup.dk | www.liftup.dk | CVR DK-1015 3964
11
Once the lift is in the position as the picture below, you can fix the wall profiles (left and right)
to the wall.
Remember to use the mounting guides or respect the
following distance between wall profiles: 800 mm between
wall profiles for the EasyLift 800, 900 mm for the EasyLift
900 and 1100 mm for the EasyLift 1100.
ATTENTION! Make sure that the wall profiles are 100% vertically mounted, and
the distance between them is exact.
2.4 Attachment with wall profiles and door; EasyLift 800/900
The lift is normally delivered almost fully assembled. The two wall profiles need to be fitted to
the adjoining wall to ensure a stable performance.
Approach the lift to the wall and place the wall profiles (the example below is with a door
mounted on the left-hand side).
Fixing points:
Use the appropriate
fixing screw, adapted
to the wall material
