3.
Release the outer actuator tube from
the extension pipe. Use a flat pliers
to bend the sheet metal lock on the
extension tube. Pull the rest of the
assembled spindle unit out from the
outer actuator tube.
4.
Release the middle actuator tube
from the top bracket on the spindle
unit. Use a small screw driver or
similar to bend the sheet metal locks.
5.
Pull the spindle unit out from the
outer actuator tube.
6.
Insert new spindle unit and mount actuator using this guide in reverse order.
Please be careful not to damage wires when sliding the actuator tubes together.
