INSTALLATION & SERVICE MANUAL – EASYLIFT – UK VERS 1.5
Liftup A/S Hagensvej 21| DK-9530 Støvring | Denmark | T: +45 96 86 30 20 | M: support@liftup.dk | www.liftup.dk | CVR DK-1015 3964
8
Place cable, running
from lift through E-
wire, inside the cover
for E-wire. Mount
cover for E-wire to
the RH side wall
profile*.
* If the lift is placed next to a wall on the right-hand side, do this before mounting the wall
profile to the wall.
E-wire correctly mounted and lift mounted to wall profiles.
The bottom rail must be fitted to the floor, towards the adjoining wall, just below the lift. The
bottom rail must be placed exactly between the two wall profiles. After fitting the bottom rail
to the floor, connect the cables from lift, door*, ramp* and/or safety barrier* as described in
chapter 3, and mount the cover to protect the control unit.
