Section 4. Electrical connections Page 19 / 107
4.3. Digital audio input connector
UMX-OPT-TX150R has standard RCA receptacles for digital coaxial audio input.
RCA receptacle RCA plug
Nr.
Name
1
S/PDIF input or output
2
Plastic insulator
3
GND
Table 4-3. RCA connector pin assignments for digital audio
Info: Plugs and sockets on consumer equipment are conventionally color-coded by
CEA/CEDIA-863-B (ANSI) to aid correct connections. According to the standard
Lightware uses orange colored RCA connectors for S/PDIF signals.
4.4. DVI-I input
The transmitter unit provides standard 29 pole DVI-I connectors for DVI-D (digital) or
DVI-A (analog) inputs. This way, users can plug in any DVI connector, but keep in mind
that the transmitter unit accepts single link DVI, HDMI or analog (such as VGA or
RGBHV) signals on the DVI input.
Always use high quality DVI cable for connecting sources and displays.
29 pole DVI-I connector
Pin
Signal
Pin
Signal
Pin
Signal
1
TMDS Data2-
9
TMDS Data1-
17
TMDS Data0-
2
TMDS Data2+
10
TMDS Data1+
18
TMDS Data0+
3
TMDS Data2 Shield
11
TMDS Data1 Shield
19
TMDS Data0 Shield
4
not connected
12
not connected
20
not connected
5
not connected
13
not connected
21
not connected
6
DDC Clock
14
+5V Power
22
TMDS Clock Shield
7
DDC Data
15
GND (for +5V)
23
TMDS Clock+
8
Analog Vertical Sync
16
Hot Plug Detect
24
TMDS Clock-
C1
Analog Red
C2
Analog Green
C3
Analog Blue
C4
Analog Horizontal Sync
C5
GND
Table 4-4. DVI-I connector pin assignments
000
0
3
2
1
C1
C2
C4
C3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
C5
