11. Commands – Quick summary
Device Status commands
Section
Command
View product type
10.3.1
{I}
View serial number
10.3.2
{S}
View Firmware version of the CPU
10.3.3
{F}
View installed controllers’ firmware
10.3.4
{FC}
View device’s temperature
10.3.5
{ST}
View CPU firmware compile time
10.3.6
{CT}
View installed I/O boards
10.3.7
{IS}
Query all port status
10.3.8
{PS}
System commands
Section
Command
Query current control protocol
10.4.1
{P_?}
Change RS-232 baud rate
10.4.2
{RS232BAUD=<rate>}
Query RS-232 baud rate
10.4.3
{RS232BAUD=?}
Reload factory defaults
10.4.4
{FACTORY=<f1>;<f2>;…;<fx>}
Set the RS-232 operation mode
10.4.5
{RS232=<mode>}
Query the RS-232 operation mode
10.4.6
{RS232=?}
Clear HDCP key cache
10.4.7
{:HDCPRESET}
Count HDCP keys
10.4.8
{:HDCPTEST<in>@<num>}
Restart
10.4.9
{RST}
View error list
10.4.10
{ELIST=?}
Configure remote alerts
10.4.11
{ELEVELSEND#<p>=<0>;<1>;
<2>;<3>;<4>}
Query level of remote alerts
10.4.12
{ELEVELSEND#<p>=?}
Set the video priority settings
10.4.13
{VIDEOPRIORITY=<vpmode>}
Query the video priority settings
10.4.14
{VIDEOPRIORITY=?}
Set the audio priority settings
10.4.15
{AUDIOPRIORITY=<apmode>}
Query the audio priority settings
10.4.16
{AUDIOPRIORITY=?}
EDID router commands
Section
Command
Save EDID to user memory (Learn EDID)
10.5.1
{<loc1>:<loc2>}
View emulated EDIDs on all inputs
10.5.2
{VEDID}
Watch EDID validity table
10.5.3
{WV<type>}
View EDID header
10.5.4
{WH<loc>}
Download EDID content from the
10.5.5
{WE<loc>}
Upload EDID content to the
10.5.6
{WL#<loc>}
Delete EDID from memory
10.5.7
{DE<loc>}
