Section 8. Remote operation Page 53 / 107
8. Remote operation
UMX-OPT-TX150R can be controlled through various interfaces remotely. This makes it
possible to use functions that are not accessible via the front panel. Also, this helps
system integrators and operators to control multiple devices in a big system through a
single user interface.
8.1. Control interfaces
Users can connect to the matrix through
 USB
 Serial port (RS-232)
After establishing connection, there is no difference between connection types (except
some rare cases, which are uniquely noted).
The available remote connections and the relating chapters are listed below.
User interface
Connection type
further
information
USB port
RS-232
serial port
Lightware matrix
controller software


chapter 9
on page 54
third party control
system
no

chapter 10
on page 69
Table 8-1. Available remote connections
8.2. Multiple simultaneous connections
The transmitter allows simultaneous remote control over multiple interfaces. USB and
Serial connections can be used at the same time.
8.3. Serial port settings
UMX-OPT-TX150R uses RS-232 communication port. The device uses standard RS-232
interface with the following default settings:
57600 Baud, 8 data bit, 1 stop bit, no parity
The serial port baud rate can be changed with the BAUD RATE rotary (addresses
#1 .. #4) on the rear panel (section 5.4.4 on page 26) or remotely by protocol
command - in case of #0 BAUD RATE rotary state (section 10.4.2 on page 73).
