Lightware UMX-OPT-TX150R User Manual

UMX-OPT-TX150R
User’s Manual
Section 10. Programmers reference Page 87 / 107
10.8.2. Query input port properties
Description: Check status of the input ports.
Format
Example
Command
{:DVII#<in>@<S/A>I=?}
→
{:dvii#1@si=?}
Response
(DVII#<in>@<S/A>I=
<VIDEO>;
<X1>;
<X2>;
<HDCP>;
<STATUS>;
<SOURCE>;
<ATIM1/DCS>;
<ATIM2/DRES>;
<ARES/HAUDIO>;
<HASAMP>;
<HCH>;)CrLf
←
(DVII#1@SI=
D;
x;
x;
1;
3;
H;
20;
1920x1080p60;
P;
48;)CrLf
Legend: Please read section 10.8.1 on page 84.
Explanation: This command queries the HDMI input port properties.
10.8.3. Set analog timing properties
Description: This command changes the setup of the analog timing data.
Format
Example
Command
{:ANALOG#<in>@<S/A>I=
<PHS>;<FHS>;
<HS>;<VS>;
<HP>;<VP>;}
→
{:analog#2@si=
10;2160;
1600;1200;
455;41;}
Response
(DVII#<in>@<S/A>I=
<PHS><FHS>;
<HS>;<VS>;
<HP>;<VP>;
<LCF>;
<FORM>;<VSP>;<HSP>;
<FPS>;)CrLf
←
(ANALOG#2@SI=
10;2160;
1600;1200;
455;41;
1124;
P;-;-;
50;)CrLf
Legend: <S/A>: Affected ports:
S = single selected input
A = all inputs
<PHS> Phase
<FHS> Full Horizontal Size
<HS> Horizontal Size
<VS> Vertical Size
<HP> Horizontal Position
<VP> Vertical Position
Info: The following parameters cannot be set, they only appear in response.
<LCF> Full Vertical Size (Line Count per Field)
<FORM> Format: Progressive or Interlaced
<VSP> Vertical Sync. Polarity
<HSP> Horizontal Sync. Polarity
<FPS> Frame Per Sec in Hz
