Lightware UMX-OPT-TX150R User Manual

Page 42 / 107 Section 6. Operation of UMX-OPT-TX150R
6.8.3. The assigning table
To help understand the EDID memory structure see the matching table below. It shows
all the EDIDs, their short descriptions and their references.
Number
on DVI-D
EDID rotary
EDIDs for DVI-D Input
EDID reference
in protocol
#0
Copy from SC MM OUT (Dynamic EDID)
D01
#1
Factory EDID Universal HDMI (default)
F01
#2
Factory EDID (DVI) 1024x768@60
F02
#3
Factory EDID (HDMI) 1280x720p@60
F03
#4
Factory EDID (HDMI) 1920x1080p@60
F04
#5
Factory EDID (DVI) 1920x1200@60
F05
#6
User EDID (def.: Univ. HDMI EDID)
U01
#7
User EDID (def.: Univ. HDMI EDID)
U02
#8
User EDID (def.: Univ. HDMI EDID)
U03
#9
User EDID (def.: Univ. HDMI EDID)
U04
Number
on DVI-A
EDID rotary
EDIDs for DVI-A Input
EDID reference
in protocol
#0
Copy from SC MM OUT (Dynamic EDID)
D01
#1
Factory EDID Universal Analog (default)
F06
#2
Factory EDID (Analog) 1024x768@60
F07
#3
Factory EDID (Analog) 1280x720@60
F08
#4
Factory EDID (Analog) 1920x1080@60
F09
#5
Factory EDID (Analog) 1920x1200@60
F10
#6
User EDID (def.: Univ. Analog EDID)
U05
#7
User EDID (def.: Univ. Analog EDID)
U06
#8
User EDID (def.: Univ. Analog EDID)
U07
#9
User EDID (def.: Univ. Analog EDID)
U08
Number
on VGA
EDID rotary
EDIDs for VGA Input
EDID reference
in protocol
#0
Copy from SC MM OUT (Dynamic EDID)
D01
#1
Factory EDID Universal Analog (default)
F11
#2
Factory EDID (Analog) 1024x768@60
F12
#3
Factory EDID (Analog) 1280x720@60
F13
#4
Factory EDID (Analog) 1920x1080@60
F14
#5
Factory EDID (Analog) 1920x1200@60
F15
#6
User EDID (def.: Univ. Analog EDID)
U09
#7
User EDID (def.: Univ. Analog EDID)
U10
#8
User EDID (def.: Univ. Analog EDID)
U11
#9
User EDID (def.: Univ. Analog EDID)
U12
Number
on HDMI
EDID rotary
EDIDs for HDMI Input
EDID reference
in protocol
#0
Copy from SC MM OUT (Dynamic EDID)
D01
#1
Factory EDID Universal HDMI (default)
F16
#2
Factory EDID (DVI) 1024x768@60
F17
#3
Factory EDID (HDMI) 1280x720p@60
F18
#4
Factory EDID (HDMI) 1920x1080p@60
F19
#5
Factory EDID (DVI) 1920x1200@60
F20
#6
User EDID (def.: Univ. HDMI EDID)
U13
#7
User EDID (def.: Univ. HDMI EDID)
U14
#8
User EDID (def.: Univ. HDMI EDID)
U15
#9
User EDID (def.: Univ. HDMI EDID)
U16
