Section 10. Programmers reference Page 93 / 107
<LCF>: 28.6363M / (256 * fvsync)
<FCL>: Number of lines in a whole picture
<LCVS> Number of lines during v.sync
<SCN> Screen scan type:
0 = progressive
1 = interlaced
<VSPP> V.sync polarity
0 = negative
1 = positive
<HSPP> H.sync polarity
0 = negative
1 = positive
<VPL> Vertical position in lines
<HPP> Horizontal position in pixels
<VSL> Vertical size in lines
<HSP> Horizontal size in pixels
<FHSP> Full horizontal size in pixels
<PHS> Phase (0 .. 31)
Explanation: One preset was saved to the input port 2.
10.8.20. Delete preset from all input ports
Description: This command deletes the desired from all analog input ports.
Format
Example
Command
{:AF#<in>@SI=DELALL;<PID>}
→
{:af#2@si=delall;1}
Response
(AF DELETED)CrLf
←
(AF DELETED)CrLf
Legend: <PID> Preset ID number
Explanation: This command is reserved for compatibility reasons.
10.9. Output properties
The following commands are setting up the properties of the output ports. If only one or a
few parameters have to be modified, the protocol enables to mask the other parameters,
so they can stay untouched. To mask a parameter use “x” or “X” as its value.
Example: {:HDMI#1@SO=H;x;x;x;1;} Set output port no. 2 to HDMI 24 bit.
Info: If the input port is not a selected, active port and this port is affected by an input
command the response will be N/A.
10.9.1. Set output video properties
Description: This command is for configuring output port settings.
Format
Example
Command
{:HDMI#<out>@<S/A>O=
<MODE>;
<CSPAC>;
<CRANG>;
<SUBS>;
<HDCP>;}
→
{:HDMI#1@SO=H;x;x;x;1;}
Response
(HDMI#<out>@<S/A>O=
G<CON><MODE><SIG>
<HDCP><HPD>;
O<MODE><CSPAC>
<CRANG>;<SUBS> <HDCP>)
M<HSUP><AUTH><REP>
<YUV4><YUV2>
<AUD><PCM><DC>CrLf
←
(HDMI#1@SO=G0H100;OHAAA1;)CrLf
Legend for command:
