Section 11. Commands – Quick summary Page 97 / 107
Input settings
Section
Command
Set input port properties
10.8.1
{:DVII#<in>@<S/A>I=<VIDEO>;
<X1>;<X2>;<HDCP>}
Query input port properties
0
{:DVII#<in>@<S/A>I=?}
Set analog timing properties
10.8.3
{:ANALOG#<in>@<S/A>I=<PHS>
;<FHS>;<HS>;<VS>;<HP>;<VP>;}
Query analog timing properties
0
{:ANALOG#<in>@<S/A>I=?}
Reset analog timing properties
10.8.5
{:ANALOG#<in>@<S/A>I=
RESET}
Set analog color properties
10.8.6
{:PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;
<DF_CHC>;<G_CHA>;<G_CHB>;
<G_CHC>;<O_CHA>;<O_CHB>;
<O_CHC>;<CONT>;<SAT>;
<BRIGHT>;<HUE>;)
Save analog color properties
10.8.7
{:PICTURE#<in>@<S/A>I=SAVE}
Query analog color properties
10.8.8
{:PICTURE#<in>@<S/A>I=?}
Reset analog color properties
10.8.9
{:PICTURE#<in>@<S/A>I=
FACTORY}
Set analog input audio parameters
10.8.10
{:AUDIN#<in>@<S/A>I=<VOL>;
<BAL>;<GAIN>;<PHS>;<DCF>}
Query analog input audio properties
10.8.11
{:AUDIN#<in>@<S/A>I=?}
Set the no sync picture properties
10.8.12
{:SETBG#<in>@<S/A>I=
<RED>;<GREEN>;<BLUE>;
<nss>}
Query the no sync picture properties
10.8.13
{:SETBG#<in>@<S/A>I=?}
Query timings of the incoming signal
10.8.14
{GETTIMINGS#<in>@<S/A>=?}
Save preset
10.8.15
{:AF#<in>@SI=<IPS>}
Delete preset
10.8.16
{:AF#<in>@SI=DEL;<PID>}
Delete all presets
10.8.17
{:AF#<in>@SI=DEL;255}
Clone preset
10.8.18
{:AF#<in>@SI=CL;<PID>}
List presets
10.8.19
{:AF#<in>@<S/A>I=LIST}
Delete preset from all input ports
10.8.20
{:AF#<in>@SI=DELALL;<PID>}
Output settings
Section
Command
Set output video properties
10.9.1
{:HDMI#<out>@<S/A>O=
<MODE>;<CSPAC>;<CRANG>;
<SUBS>;<HDCP>;}
Query output video properties
10.9.2
{:HDMI#<out>@<S/A>O=?}
