Linde H 80 D - Page 102

Service Training
Page 4.2
Section 44
09.04
Pull off casing.
Screw mounting rail on casing.
Put threaded rod on drive shaft.
Renew radial shaft seal (arrow).
Dismount securing ring. The radial shaft seal is pasted in
with Loctite.
Dismounting sequence:
1 Casing with multi-disc brake
2 Planetary carrier 2
3 Groove nut
4 Taper roller bearing
5 Casing
