Linde H 80 D - Engine Specifications

Page 20
Section 4.1
Service Training
09.06
4.1.2.2 ENGINE SPECIFICATIONS
Engine model BF6M 2012 E
Displacement 6060 cc
Power 74.9 kW at 2200 rpm
Opening pressure of injection valve 260 bar
Compression ratio 19 : 1
Compression 30 - 38 bar
Maximum difference in pressure 4 bar
Firing order 1 - 5 - 3 - 6 - 2 - 4
Valve clearence (cold) inlet: 0,3
+ 0,1
mm
outlet: 0,5
+ 0,1
mm
Lower idling speed 800 rpm
Upper idling speed 2300
+ 50
rpm
Oil pressure at lower idling speed
and 125 °C oil temperature min. 0,8 bar
Count the cylinders beginning at the flywheel end.
